Sprites, text, animations, gradients, buttons, scrolling

Repository: github.com/dekiengine/deki-2d · Latest release: 0.19.0 · Needs engine 0.19.0+ · Requires: deki-rendering, deki-input

Install with DekiEditor --packages-add deki-2d <project>, or from the Package Manager. The engine's own components and C++ API are in the Deki docs.

Shown in the editor as 2D.

Components

Component	Category	Description
AnimationComponent	2D	Plays a frame animation asset on the object's sprite.
ButtonComponent	2D	Makes the object a button: tracks hover and press, and fires a click callback.
ButtonStyleComponent	2D	Gives a button its look per state, by tinting or by swapping sprites.
ClipComponent	Core	Clips its children's rendering to a rectangle.
GradientComponent	2D	Draws a procedural gradient: linear, radial or conical.
RollerComponent	2D	Picker wheel: spins through a list of values with momentum and snaps to one.
ScrollComponent	2D	Scrolls its children by dragging, with momentum.
ScrollElement	2D	Declares one list item's size so its Scroll Component can lay the list out.
SortingGroupComponent	2D	Makes its children sort together as one unit against the rest of the scene.
SpriteComponent	2D	Draws a sprite, with tint, flip, and tiled or 9-slice modes.
TextComponent	2D	Draws text with a bitmap font, alignment and word wrap.

Feature flags

Parts you can leave out of a build. A feature with a define is switched there; the rest are stripped with their components.

Feature	Define	Default
Sprites	DEKI_FEATURE_SPRITE	on
Text	DEKI_FEATURE_TEXT	on
Animation	DEKI_FEATURE_ANIMATION	on
Gradients	DEKI_FEATURE_GRADIENT	on
Buttons	DEKI_FEATURE_BUTTON	on
Scrolling	DEKI_FEATURE_SCROLL	on
Rollers	DEKI_FEATURE_ROLLER	on
Clipping	DEKI_FEATURE_CLIP	on
Sorting Groups	DEKI_FEATURE_SORTING_GROUP	on

Component reference

AnimationComponent

Plays a frame animation asset on the object's sprite.

Inspector name: Animation Component · Category: 2D · Type: Deki2D::AnimationComponent

Property	Type	Default	Description
animation	AssetRef (FrameAnimationData)	""	A frame animation asset, which lists the frames and how long each is held.
currentSequence	int32	0	Which named sequence is playing, by index. Sequences are the separate animations inside one asset, such as idle and walk.
currentFrame	int32	0	Frame within the current sequence. Set it to scrub; it is also useful to read while debugging.
isPlaying	bool	false	Whether the animation is advancing. Clearing this freezes it on the current frame rather than resetting it.
hasFinished	bool	false	Set when a non-looping sequence reaches its last frame. Read it to know when to move on.
playOnceOverride	bool	false	Play the current sequence once even if the asset marks it as looping. Cleared when the sequence changes.

ButtonComponent

Makes the object a button: tracks hover and press, and fires a click callback.

Inspector name: Button Component · Category: 2D · Type: Deki2D::ButtonComponent

Property	Type	Default	Constraints	Description
inputCollider	ObjectRef (InputCollider)	0		The hit area that makes this button clickable. Without one the button has no way to notice a press.
state	enum	"Normal"	Normal, Hovered, Pressed, Disabled	Normal, hovered, pressed or disabled. Set by input; a style component watches it to decide what to draw.
isEnabled	bool	true		A disabled button ignores input and reports the disabled state, so it can be greyed out rather than hidden.

ButtonStyleComponent

Gives a button its look per state, by tinting or by swapping sprites.

Inspector name: Button Style Component · Category: 2D · Type: Deki2D::ButtonStyleComponent

Property	Type	Default	Constraints	Description
button	ObjectRef (ButtonComponent)	0		The button whose state drives this styling. Usually the button on the same object.
sprite	ObjectRef (SpriteComponent)	0		The sprite this styling changes. Usually the sprite on the same object.
transition	enum	"ColorTint"	ColorTint, SpriteSwap	Whether pressing swaps the tint colour or swaps the sprite outright. Colour is cheaper; separate sprites let the shape change.
normalColor	Color	"#FFFFFFFF"	shown when transition allows	Tint while the button is idle.
hoveredColor	Color	"#C8C8C8FF"	shown when transition allows	Tint while the pointer is over it. On a touch-only device this is rarely seen.
pressedColor	Color	"#A0A0A0FF"	shown when transition allows	Tint while it is held down. This is the feedback that tells someone the press registered.
disabledColor	Color	"#80808080"	shown when transition allows	Tint while the button is disabled. Usually faded or desaturated.
normalSprite	AssetRef (Sprite)	""	shown when transition allows	Sprite while idle, in sprite-swap mode.
hoveredSprite	AssetRef (Sprite)	""	shown when transition allows	Sprite while hovered, in sprite-swap mode.
pressedSprite	AssetRef (Sprite)	""	shown when transition allows	Sprite while held, in sprite-swap mode.
disabledSprite	AssetRef (Sprite)	""	shown when transition allows	Sprite while disabled, in sprite-swap mode.

ClipComponent

Clips its children's rendering to a rectangle.

Inspector name: Clip Component · Category: Core · Type: Deki2D::ClipComponent

Property	Type	Default	Constraints	Description
width	float	6.25	in m	Width of the clipping window in meters. Children are cut off at this edge.
height	float	6.25	in m	Height of the clipping window in meters.
sortingOrder	int32	0		Draw order of the clipped group as a whole against everything outside it.

GradientComponent

Draws a procedural gradient: linear, radial or conical.

Inspector name: Gradient Component · Category: 2D · Type: Deki2D::GradientComponent

Property	Type	Default	Constraints	Description
gradientType	enum	"Linear"	Linear, Radial, Conical	Linear runs the colours along the angle below. Radial runs them out from the centre point.
tileMode	enum	"None"	None, Horizontal, Vertical, Both, Mirror	What happens past the last stop: hold the end colour, repeat the ramp, or mirror it back.
ditherMode	enum	"Ordered4x4"	None, Ordered2x2, Ordered4x4, Ordered8x8, Ordered16x16	Dithering hides the banding a smooth ramp shows on a 16-bit display, by trading it for a fine speckle.
ditherScale	uint8	1		Size of the dither pattern in art pixels. 1 dithers pixel by pixel; 2, 4, 8 or 16 make chunkier blocks for a retro look.
width	float	0	in m	Width of the gradient in meters.
height	float	0	in m	Height of the gradient in meters.
angle	float	0	in rad	Direction a linear gradient runs, in radians. 0 runs left to right.
centerX	float	0.5		Centre of a radial gradient across the width, 0 to 1. 0.5 is the middle.
centerY	float	0.5		Centre of a radial gradient down the height, 0 to 1.
radius	float	0.5		How far a radial gradient reaches before the last stop, relative to the size.
stopCount	uint8	2		How many of the four colour stops are used. The rest are ignored.
stop1Position	float	0		Where the first stop sits along the ramp, 0 to 1.
stop1Color	Color	"#FFFFFFFF"		Colour at the first stop.
stop2Position	float	1	shown when stopCount allows	Where the second stop sits along the ramp, 0 to 1.
stop2Color	Color	"#000000FF"	shown when stopCount allows	Colour at the second stop.
stop3Position	float	0	shown when stopCount allows	Where the third stop sits, 0 to 1. Used when the stop count is 3 or more.
stop3Color	Color	"#000000FF"	shown when stopCount allows	Colour at the third stop.
stop4Position	float	0	shown when stopCount allows	Where the fourth stop sits, 0 to 1. Used when the stop count is 4.
stop4Color	Color	"#000000FF"	shown when stopCount allows	Colour at the fourth stop.
tileWidth	float	0	in m	Width of one repeat when the tile mode repeats or mirrors.
tileHeight	float	0	in m	Height of one repeat when the tile mode repeats or mirrors.

Inherits sortingOrder, ignoreClip, pixelSnap, alphaMode from RendererComponent.

RollerComponent

Picker wheel: spins through a list of values with momentum and snaps to one.

Inspector name: Roller Component · Category: 2D · Type: Deki2D::RollerComponent

Property	Type	Default	Constraints	Description
inputCollider	ObjectRef (InputCollider)	0		The hit area that catches the drag. Without one the roller cannot be spun.
width	float	6.25	in m	Width of the roller in meters.
itemHeight	float	1.875	in m	Height of one unselected row, in meters.
visibleRows	int32	3		How many rows are shown at once, including the selected one. Odd numbers centre the selection.
infiniteScroll	bool	false		Wrap around from the last option to the first, so the roller spins without ends.
reverseDrag	bool	false		Invert the drag direction.
options	Array<string>	[]		The list of choices, in order.
selectedIndex	int32	0		Which option is currently chosen, counting from 0.
deceleration	float	0.95		How quickly a flick slows down. Higher settles sooner.
snapSpeed	float	8		How fast the roller settles onto the nearest option once it has slowed. Higher snaps harder.
selectedItemHeight	float	2.5	in m	Height of the selected row, in meters. Making it taller than the others is what marks the selection.
selectedColor	Color	"#FFFFFFFF"		Text colour of the selected row.
normalColor	Color	"#808080FF"		Text colour of the rows either side.
selectedFontSize	int32	24		Editor preview size for the selected row. The device draws at the font asset's baked size.
normalFontSize	int32	16		Editor preview size for the unselected rows.

ScrollComponent

Scrolls its children by dragging, with momentum.

Inspector name: Scroll Component · Category: 2D · Type: Deki2D::ScrollComponent

Property	Type	Default	Constraints	Description
inputCollider	ObjectRef (InputCollider)	0		The hit area that catches the drag. Without one nothing can scroll it.
mode	enum	"NonTemplate"	NonTemplate, Template	Whether items come from the children already present or are spawned from the scene below as they are needed.
itemScene	AssetRef (Scene)	""	shown when mode allows	Scene spawned once per item, in the spawning mode. Each copy is filled in as it scrolls into view.
direction	enum	"Vertical"	Vertical, Horizontal	Vertical or horizontal travel.
itemSpacing	float	0	in m	Gap between items in meters.
paddingTop	float	0	in m	Empty space before the first item, in meters.
paddingBottom	float	0	in m	Empty space after the last item, in meters.
paddingLeft	float	0	in m	Empty space at the left edge, in meters.
paddingRight	float	0	in m	Empty space at the right edge, in meters.
deceleration	float	0.95		How quickly a flick slows down. Higher stops sooner; lower keeps gliding.
bounceStiffness	float	0.15		How hard the list springs back after being dragged past its end. Higher snaps back faster.
enableBounce	bool	true		Let the list be dragged past its end and spring back. Off, it stops dead at the edge.
enableInertia	bool	true		Keep moving after the finger lifts. Off, the list stops the moment the drag ends.
reverseDrag	bool	false		Invert the drag direction, so content follows the finger the other way.

ScrollElement

Declares one list item's size so its Scroll Component can lay the list out.

Inspector name: Scroll Element · Category: 2D · Type: Deki2D::ScrollElement

Property	Type	Default	Constraints	Description
width	float	6.25	in m	Width of one item in meters. The scroll uses it to work out spacing and how far it can travel.
height	float	3.75	in m	Height of one item in meters.

SortingGroupComponent

Makes its children sort together as one unit against the rest of the scene.

Inspector name: Sorting Group Component · Category: 2D · Type: Deki2D::SortingGroupComponent

Property	Type	Default	Description
sortingOrder	int32	0	Draw order for this object's whole subtree, treated as one unit. Children keep their order relative to each other but the group moves together, which stops one child sorting between another group's children.

SpriteComponent

Draws a sprite, with tint, flip, and tiled or 9-slice modes.

Inspector name: Sprite Component · Category: 2D · Type: Deki2D::SpriteComponent

Property	Type	Default	Constraints	Description
sprite	AssetRef (Sprite)	""		The image to draw. Sprites come from a texture asset, either whole or cut out of a spritesheet.
tintColor	Color	"#FFFFFFFF"		Multiplied into every pixel. White leaves the image alone; darker tints shade it, and the alpha fades it out.
renderMode	enum	"Normal"	Normal, Tiled, NineSlice	Normal draws the sprite once. Tiled repeats it to fill the size below. Nine-slice stretches the middle and leaves the corners intact, which is what you want for panels and buttons.
flipHorizontal	bool	false		Mirror left to right. Cheaper than a second sprite and the usual way to face a character the other way.
flipVertical	bool	false		Mirror top to bottom.
width	float	0	in m; shown when renderMode allows	Drawn size in meters. Left at 0 the sprite's own pixel size is used, converted through the project's pixels-per-meter.
height	float	0	in m; shown when renderMode allows	Drawn size in meters. Left at 0 the sprite's own pixel size is used, converted through the project's pixels-per-meter.

Inherits sortingOrder, ignoreClip, pixelSnap, alphaMode from RendererComponent.

TextComponent

Draws text with a bitmap font, alignment and word wrap.

Inspector name: Text Component · Category: 2D · Type: Deki2D::TextComponent

Property	Type	Default	Constraints	Description
text	string	""		The string to draw. Newlines start a new line, and with a width set, lines wrap between words to fit it.
font	AssetRef (BitmapFont)	""		A bitmap font asset. Fonts are baked to a fixed size, so pick one close to the size you want rather than scaling far from it.
fontSize	int32	16		Size used for the editor preview only. What the device draws is the size the font asset was baked at.
width	float	6.25	in m	Width of the text box in meters. Alignment is measured against this, so it matters even when the text is shorter.
height	float	1.5	in m	Height of the text box in meters. Vertical alignment is measured against this.
color	Color	"#FFFFFFFF"		Colour of the glyphs.
decorationColor	Color	"#000000FF"		Colour of the outline or shadow, when the font asset was baked with one. Ignored by a plain font.
pixelScale	int32	1		Whole-number magnification. 2 draws every glyph pixel as a 2x2 block, which keeps a pixel font crisp instead of blurring it.
align	enum	"Left"	Left, Center, Right	Horizontal placement inside the width above.
verticalAlign	enum	"CapCenter"	Top, Middle, Bottom, CapCenter, XCenter, TypoCenter, Baseline	Vertical placement inside the height above. Cap-centre lines up the capital letters, which usually looks centred to the eye; true centre includes descenders.

Inherits sortingOrder, ignoreClip, pixelSnap, alphaMode from RendererComponent.

Changelog

0.19.0 Changed

minEngine 0.19.0: built against engine 0.19.0, whose component metadata records the package each class is in. A build of this package from before does not load and is rebuilt.

Added

Japanese, Simplified Chinese and Korean: editor/lang/ja.json, zh.json and ko.json translate the names, tooltips and enum values this package's components show in the Inspector.
The package's editor text goes through the editor's translation (Tr), so it shows in the editor's language. Needs the editor release that adds Localization.h; raise minEngine to it when releasing.

0.18.2 Added

sprite_nine_slice CLI and MCP tool: sets an image's 9-slice borders.

Changed

A 9-slice or tiled sprite in RGB565 or RGB565A8 without a chroma key has its tint baked into the image it keeps of itself, baked again when the tint changes, and is drawn untinted: a copy of its opaque runs instead of a tint on every pixel, every frame. Tinted panels were most of the time in the T-Deck demo's GPS and LoRa screens, which went from 55 to 63 fps.

Fixed

A dithered gradient kept its pattern only at whole-number zoom: in the editor's scene view its Bayer cells were laid out in screen pixels, rounded to whole ones, and drifted against the gradient's own pixels, so each zoom showed a different, uneven stipple. The pattern is now laid out on the art grid like the colour, and zooming in only magnifies it. Zoomed far in, the bake was also capped below the screen's density and scaled twice, which made some cells twice as wide as others: drawn at its own size or larger it is now baked at art size and magnified once, so every cell is the same size and zooming no longer re-bakes it. Drawn smaller than its own size, the pattern stays a regular stipple in screen pixels, as in 0.17. On the device at 1:1 the picture is unchanged.

Earlier releases: CHANGELOG.md.

Generated from the package's reflection data (engine 0.19.0). Property names are the keys used in scene files. Renames keep an alias (compatibility).
