ESP32 memory, filesystem, serial, and SD card providers

Repository: github.com/dekiengine/deki-esp32-integration · Latest release: 1.1.0 · Needs engine 1.2.0+ · Requires: deki-wifi, deki-ble, deki-http, deki-i2s, deki-uart, deki-i2c, deki-sdcard, deki-rendering

Install: DekiEditor --packages-add deki-esp32-integration <project>, or add it in the Package Manager. Part of Deki; the engine's own components and the C++ API are documented there.

Shown in the editor as ESP32 Integration.

Components

Component	Category	Description
ESP32SerialSetup	ESP32 HAL	Answers the editor's commands over the ESP32's serial port.

Feature flags

Compile-time features the package exposes (package.json):

Feature	Define	Default
Memory	DEKI_FEATURE_ESP32_MEMORY_SETUP	on
File System	DEKI_FEATURE_ESP32_FILE_SYSTEM_SETUP	on
Serial Commands	DEKI_FEATURE_ESP32_SERIAL_SETUP	on
SD Card (ESP-IDF)	DEKI_FEATURE_ESP32_SD	on
I²C (ESP-IDF)	DEKI_FEATURE_ESP32_I2C	on
UART (ESP-IDF)	DEKI_FEATURE_ESP32_UART	on
I²S (ESP-IDF)	DEKI_FEATURE_ESP32_I2S	on
S3 SIMD Blit Kernels	DEKI_FEATURE_ESP32_BLIT_SIMD	on
WiFi STA + scan (ESP-IDF)	DEKI_FEATURE_ESP32_WIFI	on
BLE (NimBLE)	DEKI_FEATURE_ESP32_BLE	on
HTTPS client (ESP-IDF)	DEKI_FEATURE_ESP32_HTTP	on

Component reference

ESP32SerialSetup

Answers the editor's commands over the ESP32's serial port.

Inspector name: ESP32 Serial Setup · Category: ESP32 HAL · Type GUID: c9d4eaf6-5081-4c3d-bf27-a04f9e6d8c51

Property	Type	Default	Constraints	Description
baudRate	int32	115200	9600 to 921600	Serial baud rate

Generated from the package's reflection metadata by the Deki documentation build (engine 1.3.0). Reflected property names are the keys scene files use; a rename ships with an alias, see COMPATIBILITY.md.
