可视化状态机。在画布上布置状态、分组和转换，每个状态内部有一条动作流。

仓库：github.com/dekiengine/deki-fsm · 最新版本：0.19.0 · 需要引擎 0.19.0 或更高版本 · 依赖：deki-nodegraph, deki-2d, deki-tween

使用 DekiEditor --packages-add deki-fsm <project> 或通过包管理器安装。引擎自身的组件和 C++ API 见 Deki 文档。

在编辑器中显示为 **FSM**。

组件

组件	类别	说明
FsmComponent	逻辑	在此对象上运行状态机图资源。

功能开关

可以从构建中去掉的部分。带有 define 的功能通过该 define 开关，其余的随其组件一起被剥离。

功能	define	默认值
FSM	DEKI_FEATURE_FSM	开

在此对象上运行状态机图资源。

检视器中的名称：状态机组件 · 类别：逻辑 · 类型：DekiFsm::FsmComponent

属性	类型	默认值	说明
graph	AssetRef (FsmGraph)	""	此对象运行的状态机资源。在节点图编辑器中编写。
variableOverrides	Array<string>	[]	此对象为图中变量设置的初始值，格式为 name=value（例如 speedHz=0.625）。

更新日志为英文。

minEngine 0.19.0: built against engine 0.19.0, whose component metadata records the package each class is in. A build of this package from before does not load and is rebuilt.

Japanese, Simplified Chinese and Korean: editor/lang/ja.json, zh.json and ko.json translate the names, tooltips and enum values this package's components show in the Inspector.
The package's editor text goes through the editor's translation (Tr), so it shows in the editor's language. Needs the editor release that adds Localization.h; raise minEngine to it when releasing.

Timed actions keep time when frames are long or uneven. An action that finished part way through a frame let the next one in the flow start with the whole frame again, so a flow gained time at each step, and a long frame (a scene loading, a screenshot sent from the board) moved each machine on by a different amount: the logic demo's orbs, started a phase apart, bunched up. A finished Wait, Tween Property or delayed Send Event now passes on only the time it did not use, and one frame counts as at most a second.

更早的版本：CHANGELOG.md

由包的反射数据生成（引擎 0.19.0）。属性名就是场景文件中使用的键。重命名后会保留别名（兼容性）。
