音频播放外设。通过 I²S 驱动 MAX98357 D 类功放。

仓库：github.com/dekiengine/deki-audio · 最新版本：0.19.0 · 需要引擎 0.19.0 或更高版本 · 依赖：deki-i2s

使用 DekiEditor --packages-add deki-audio <project> 或通过包管理器安装。引擎自身的组件和 C++ API 见 Deki 文档。

在编辑器中显示为 **Audio (Speaker / PCM playback)**。

组件

组件	类别	说明
MAX98357AudioComponent	传感器	通过 MAX98357A I2S 功放播放声音。

功能开关

可以从构建中去掉的部分。带有 define 的功能通过该 define 开关，其余的随其组件一起被剥离。

功能	define	默认值
MAX98357A (I²S class-D mono amp, 16-bit PCM)	DEKI_FEATURE_AUDIO_MAX98357	开

通过 MAX98357A I2S 功放播放声音。

检视器中的名称：MAX98357A 音频 · 类别：传感器 · 类型：DekiAudio::MAX98357AudioComponent

属性	类型	默认值	约束	说明
i2sPort	int32	0	0 到 1	由芯片的哪个 I2S 控制器驱动功放。大多数开发板只用一个。
bclkPin	int32	39	0 到 48	传输位时钟（BCLK）的 GPIO，每个音频位跳变一次。
lrclkPin	int32	40	0 到 48	传输字选择线（LRCLK 或 WS）的 GPIO，用于区分左右声道的采样。有些开发板标为 LRC。
dinPin	int32	5	0 到 48	向功放传输音频数据的 GPIO（DIN）。声音实际就是通过这条线传输的。
sampleRate	int32	16000	8000 到 48000	每秒的采样数。16 kHz 对语音和音效已经足够，占用内存也少；44100 是 CD 采样率，带宽开销接近三倍。
channels	int32	1	1 到 2	1 为单声道，2 为立体声。MAX98357 是单声道功放，因此除非为另一个声道再接一片，否则立体声素材会被混合为单声道。
initialVolume	int32	80	0 到 100	启动时的音量，范围 0 到 100。在第一个声音播放前生效，因此项目可以以较小音量启动，而不是满音量输出。

更新日志为英文。

minEngine 0.19.0: built against engine 0.19.0, whose component metadata records the package each class is in. A build of this package from before does not load and is rebuilt.

Japanese, Simplified Chinese and Korean: editor/lang/ja.json, zh.json and ko.json translate the names, tooltips and enum values this package's components show in the Inspector.
The package's editor text goes through the editor's translation (Tr), so it shows in the editor's language. Needs the editor release that adds Localization.h; raise minEngine to it when releasing.

minEngine 0.18.0. Reflection ABI 21: the package must be rebuilt.
Names follow the code style (deki-engine/docs/codestyle): types, functions and enum values are PascalCase, constants kPascalCase, members m_PascalCase, locals and parameters camelCase. The code is formatted with clang-format 22.
The functions the editor finds by name are PascalCase: DekiAudioRegisterComponents, DekiAudioGetAutoComponentCount, DekiAudioEnsureRegistered and the rest. Built against engine ABI 21; a build of this package from before does not load and is rebuilt.

MAX98357A: after Stop() the speaker stayed silent until a restart, because playing never turned the I2S channel back on. PlayPCM now does.
MAX98357A: PlayPCM copied the whole clip into internal RAM to apply the volume, so a long clip ran the board out of memory. It now scales a small chunk at a time.
MAX98357A: initializing twice leaked the first I2S channel, and a channel that failed to start was left open.

The former names from before 0.16.0 (bare class names, and deki-gpio's DekiEsp32::ESP32PinSetup). A scene that old is upgraded with 0.17 first.

更早的版本：CHANGELOG.md

由包的反射数据生成（引擎 0.19.0）。属性名就是场景文件中使用的键。重命名后会保留别名（兼容性）。
